1Pcs LED Display Digital PID Temperature Controller TCN5W-M Thermostat with 24Vdc Output
Product details
| Management number | 207957658 | Release Date | 2026/03/22 | List Price | $18.80 | Model Number | 207957658 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Temp Control SensorTCN5W-M 72*72mm Digital PID Temperature ControllerAdvantages1. Large dual LED display2. PID control, Auto-tuning3. Output: Relay+24Vdc4. Input: Current 4-20mASpecificationsPower supply1) 220VAC, 2)100-240VAC/DC, 3) 24VDCAllowable voltage range90-110% of rated voltagePower consumptionMax. 8VAInput specificationTCK, E, JRTDPt100, Cu50Linear current0-20mA, 4-20mALinear voltage0-5V, 0-10VDisplay accuracy±0.5%Output specification250VAC 5ARelay contact output 250VAC 5A1NO1NCSSR 12VDC±2V Below 20mA(0-5V 0-10V) Voltage output (0-5V 0-10V)(0-20mA 4-20mA) Current output (0-20mA 4-20mA)SCR output (zero-crossing output,phase shift output)Alarm outputRelay 250VAC 5A Max.two sets of alarm outputsControl methodON/OFF Position control, PID controlSampling period100msRelay life cycleMechanical above 2.5 million times, Electrical above 100000 timesDielectric strength2000VAC50/60Hz for 1min. ( between all terminals and case )Vibration0.75mm amplitude at frequency 5 to 55HZ(for1min.) in eachX5Y,Z direction for 2 hoursInsulation resistanceMin.100M( 500VDC) MEGANoise resistanceSquare shaped noise by noise simulator(pulse width 1 ys)±2kV R-phase,S-phaseMemory retentionApprox.10years(non-volatile semiconductor memory type)EnvironmentAmbient temp.(Storage):-10~50Ambient humi.(Storage): 35-85%RHProduct OverviewsPackaging & Shipping==========Hign-concerned Chemical : NoneMeasure Type : KType : KTheory : Temperature ControllerDisplay Type : DIGITALPower Type : ChargerModel Number : TCN5W-MDisplay Size : 1.9 Inches & UnderMax Measuring Temperature : 120°C & AboveStyle : EmbeddedUsage : IndustrialPower supply : 100-240VAC
- Temp Control Sensor
- Model Number : TCN5W-M
- Power supply : 100-240VAC
- Input : K
- Output 1 : Relay
- Output 2 : 24Vdc
| Department | unisex-adult |
|---|---|
| Item Weight | 1.76 ounces |
| Manufacturer | CTDOFUM |
| Number of pieces | 1 |
| Assembly required | No |
| Item model number | CTDOFUM |
| Package Dimensions | 11.81 x 7.87 x 3.94 inches |
