PCIE SATA Cards, Ports SATA III 6Gbps Controller Cards with Low Bracket, PCIE (1X 2X 4X 8X 16X) SATA3.0 Interface Expansion Cards for for Linux
Product details
| Management number | 208557247 | Release Date | 2026/03/22 | List Price | $12.83 | Model Number | 208557247 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Specification:Item Type:PCIE to SATA 3.0 Card Model:PCE8SATM01 Master: Fit forMarvell 88SE92xx+JMB5XX Interface: PCIE 1X 2X 4X 8X 16X Support System:Fit For Fit For Ubuntu Expansion Interface: x SATA3.0 Interfaces Package List:1 x Expansion Card;1 x SemiHigh Baffle;1 x Driver Disc Note:PCIE must have a slot V2.0, V1.0 will not exceed 250M, PCIE can be X1 or X16 as long as it is V2.0 version, there is spare X16 slot directly into X16 slot on. BOIS setting of the motherboard: SATA mode should be changed to AHCI, although some motherboard PCIE is version 2.0, but BOIS does not enable highspeed mode by default (gen2 high speed mode) needs to be manually turned on. In PCIE 1.0 mode, only 200 250M, 2.0 mode is below 350400M. If you don't accept it, change the motherboard. When the SATA port is used at the same time, it will slow down. It is not suitable for users who are pursuing speed. It is only used for the extended hard disk interface.
- 【 88SE9215 +JMB5XX Master】: Powerful chip 88SE9215 was adopted in this SATA sata expansion card, it make the SATA card more stable and compatible, supports each SATA 3.0 port transfer rate up to 6Gbps for AHCI boot and storage.
- 【PCIE to 8 SATA】: This PCI SATA expansion card can be expanded to 8 SATA 3.0 6Gbps ports via Pcie X1 X2 X4 X8 X16 slots. No drivers needed, Easy to install, Plug and Play.
- 【Wide Compatibility】: SATA Controller compatible with SATA6G, 3G and 1.5G hard drives. Fit for 7/8 / / / 2003 / 2008 Fit for Ubuntu support system, PCI-E 1X 2X 4X 8X 16X interface. Backward compatible with SATA2.0 SATA1.0; PCI-Express v2.0 compatible, backward compatible with PCI-Express v1.0.
- 【Excellent Heat Dissipation】: Excellent heat radiator accelerate heat dissipation, ensure long-lasting high temperature and more stable . With a low Bracket, compatible with 99% size chassis on the market.
- 【Motherboard BOIS Settings】: SATA mode should be changed to AHCI, some motherboards PCIE although 2.0 version, but the BOIS default does not open the high-speed transfer mode that (gen2 high speed mode), you need to manually open.
| Brand | Diyeeni |
|---|---|
| Color | default |
| Item Weight | 3.87 ounces |
| Manufacturer | Diyeeni |
| Operating System | Windows 7 |
| Item model number | PCIE8SATM01 |
